Forklift Starters and Alternators - Today's starter motor is typically a permanent-magnet composition or a series-parallel wound direct current electrical motor along with a starter solenoid installed on it. As soon as current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion that is situated on the driveshaft and meshes the pinion using the starter ring gear which is seen on the engine flywheel.
When the starter motor starts to turn, the solenoid closes the high-current contacts. Once the engine has started, the solenoid consists of a key operated switch that opens the spring assembly in order to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This allows the pinion to transmit drive in only one direction. Drive is transmitted in this manner through the pinion to the flywheel ring gear. The pinion remains engaged, like for instance in view of the fact that the driver fails to release the key when the engine starts or if the solenoid remains engaged because there is a short. This causes the pinion to spin separately of its driveshaft.
The actions mentioned above would prevent the engine from driving the starter. This significant step stops the starter from spinning very fast that it would fly apart. Unless adjustments were made, the sprag clutch arrangement will preclude the use of the starter as a generator if it was utilized in the hybrid scheme discussed earlier. Usually an average starter motor is meant for intermittent use that will prevent it being utilized as a generator.
The electrical components are made so as to function for roughly thirty seconds in order to stop overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical components are meant to save weight and cost. This is the reason nearly all owner's manuals for vehicles suggest the driver to pause for at least 10 seconds after every 10 or 15 seconds of cranking the engine, when trying to start an engine which does not turn over at once.
The overrunning-clutch pinion was introduced onto the marked in the early part of the 1960's. Prior to the 1960's, a Bendix drive was utilized. This particular drive system works on a helically cut driveshaft that consists of a starter drive pinion placed on it. When the starter motor begins spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, therefore engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear enables the pinion to go beyond the rotating speed of the starter. At this point, the drive pinion is forced back down the helical shaft and thus out of mesh with the ring gear.
During the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design that was developed and introduced in the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive has a latching mechanism together with a set of flyweights within the body of the drive unit. This was an enhancement in view of the fact that the standard Bendix drive utilized to be able to disengage from the ring as soon as the engine fired, though it did not stay functioning.
When the starter motor is engaged and starts turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for example it is backdriven by the running engine, and after that the flyweights pull outward in a radial manner. This releases the latch and allows the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement can be prevented previous to a successful engine start.
